LEDstrip 12V R IP67

spinner symbol
LEDstrip 12V R IP67
LEDstrip 12V R IP67
LEDstrip 12V R IP67
LEDstrip 12V R IP67
Flexible LED strips with very good colour rendering, Ra>90, and lumen output adjusted to attain a beautiful fill and raking light. The high IP degree of protection means it is suitable as decoration lighting for both indoor and outdoor use, such as a stair rail or illuminating lines around a shop window. Suits our range of aluminium profiles perfectly. Comes with 2 m of connecting cable at each end, 2pcs shrink hoses, 10pcs clips, 20pcs screws and self-adhesive tape for easy installation. Also available made to measure in optional lengths. LEDstrip 12V has a somewhat lower lumen output than LEDstrip 24V. Drivers are ordered separately according to required dimmer technology and placing.


GTIN Item Name Luminaire Lumen (lm)
LEDstrip R IP67 12V 3000K 5m 7392971125602 LEDstrip R IP67 12V 3000K 5m 1275
LEDstrip R IP67 12V 3000K lpm 7392971125619 LEDstrip R IP67 12V 3000K lpm 255

LEDstrip R IP67 12V 3000K 5m

GTIN 7392971125602
Item Name LEDstrip R IP67 12V 3000K 5m
Warranty 5 years
Light Technical Data
Light Source LED
Light Source Included Yes
Replaceability Non-replaceaable LED
LED Colour Warm White
Colour Temperature (K) 3000
Colour Rendering Index (Ra) >90
Colour Consistency (SDCM) 3
Initial Chromaticity (0.438, 0.405)
Luminous Intensity (cd) 75
Luminaire Lumen (lm) 1275
Beam Angle (°) 120
Light sharing
Light Outlet Direct
Number of Lamps (pcs) 1
Number of LED (pcs) 300
LED Pitch (mm) 16
Life Time L70 40 000h Ta 25°C
Nominel Life Time (h) 40000
Technical data
Adjustable No
Voltage (type) DC
Voltage Interval (V) 12...12
Voltage Nominal (V) 12
Power Luminaire (W) 24
System Power (W) 26,4
Efficiency Luminaire (lm/W) 53
Efficiency System (lm/W) 48
Energy Efficiency Class (EU) 2019/2015 G
Operation and Connection
Driver Included No
Driver Model Constant Voltage
Connection (type) Cable
Length Connection (cm) 200
Connection (mm2) 2x0,5
Length Connection Secondary (cm) 200
Operating Temperature -20…+40
Dimmable Yes
Color and material
Material Copper, PVC
Color White
Environmental Assessment SundaHus, Byggvarubedömningen
Measurement and installation
Operating Environment Indoor / wet locations, Outdoor
IP Degree of Protection 67
Protection Class III
Installation Surface mounted
Mounting Installation Self Adhesive Tape
Approval Marks CE
Length (mm) 5000
Width (mm) 10
Height (mm) 6
Weight (kg) 0,36
Fibres and strips
Min. Bend Radius (mm) 60
Min. Length (m) 0,05
Max. Length (m) 10
Cutting Increments (mm) 50
