LEDstrip R IP20

LEDstrip R has a good light quality and high level of colour rendering, RA>90. Perfectly suited to illuminate interior design elements, artwork or furnishings so they attain the correct lustre and the colours are perceived in the best way. All LEDstrips are perfectly suited to our range of aluminium profiles. LEDstrip 12V has a somewhat lower lumen output than LEDstrip 24V. Supplied with self-adhesive tape for simple installation.

Variants

GTIN Item Name Colour Temperature (K) Luminaire Lumen (lm)
LEDstrip R IP20 12V 3000K lpm 7392971125596 LEDstrip R IP20 12V 3000K lpm 3000 275
LEDstrip R IP20 12V 3000K 5m 7392971125589 LEDstrip R IP20 12V 3000K 5m 3000 1375
LEDstrip R IP20 12V 4000K lpm 7392971135335 LEDstrip R IP20 12V 4000K lpm 4000 300

LEDstrip R IP20 12V 3000K lpm

Description
GTIN 7392971125596
Item Name LEDstrip R IP20 12V 3000K lpm
Warranty 5 years
Light Technical Data
Light Source LED
Light Source Included Yes
LED Colour Warm White
Colour Temperature (K) 3000
Colour Rendering Index (Ra) >90
Colour Consistency (SDCM) 3
Initial Chromaticity (0.434, 0.405)
Luminous Intensity (cd) 85
Luminaire Lumen (lm) 275
Beam Angle (°) 120
Light sharing Symmetric
Light Outlet Direct
Number of Lamps (pcs) 1
Number of LED (pcs) 60
LED Pitch (mm) 16
Life Time L70 50 000h Ta 25°C
Nominel Life Time (h) 50000
Technical data
Adjustable No
Voltage (type) DC
Voltage Interval (V) 12...12
Voltage Nominal (V) 12
Power Luminaire (W) 4,8
System Power (W) 5,28
Efficiency Luminaire (lm/W) 57
Efficiency System (lm/W) 52
Energy Efficiency Class 2019/2015 G
Operation and Connection
Driver Included No
Driver Model Constant Voltage
Connection (type) Cable
Connection (mm2) 2x0,5
Operating Temperature -10...+40
Dimmable Yes
Color and material
Material Copper
Color White
Environmental Assessment SundaHus, Byggvarubedömningen
Measurement and installation
Operating Environment Indoor / dry locations
IP Degree of Protection 20
Protection Class III
Installation Surface mounted
Mounting Installation Self Adhesive Tape
Approval Marks CE
Length (mm) 1000
Width (mm) 8
Height (mm) 3
Weight (kg) 0,02
Fibres and strips
Min. Bend Radius (mm) 60
Min. Length (m) 0,05
Max. Length (m) 10
Cutting Increments (mm) 50
