LEDstrip RX Tune IP20

LEDstrip with Tune function for a strengthened feeling of warm light with a very good colour rendering, Ra>90. Gives a warmer LED colour when dimmed; from work lighting during the day to cosy lighting in the evening. LEDstrip RX Tune is perfect for indoor use in both home and public environments. We recommend using an aluminium profile with opal cover if the fitting is visible. Comes with self-adhesive tape and quick connections. Drivers are ordered separately according to required dimmer technology and location.


GTIN Item Name Luminaire Lumen (lm)
LEDstrip RX Tune IP20 24V lpm 7392971136387 LEDstrip RX Tune IP20 24V lpm 1130
LEDstrip RX Tune IP20 24V 5m 7392971136370 LEDstrip RX Tune IP20 24V 5m 5650

LEDstrip RX Tune IP20 24V lpm

GTIN 7392971136387
Item Name LEDstrip RX Tune IP20 24V lpm
Warranty 5 years
Light Technical Data
Light Source LED
Light Source Included Yes
LED Colour Tune
Colour Temperature (K) 2700
Range Colour Temperature (K) Tune 2000-2700
Colour Rendering Index (Ra) >90
Colour Consistency (SDCM) 4
Initial Chromaticity (0.4585, 0.4006)
Luminous Intensity (cd) 360
Luminaire Lumen (lm) 1130
Beam Angle (°) 120
Light sharing Symmetric
Light Outlet Direct
Number of Lamps (pcs) 1
Number of LED (pcs) 120
LED Pitch (mm) 16
Life Time L70 50 000h Ta 25°C
Nominel Life Time (h) 50000
Technical data
Adjustable No
Voltage (type) DC
Voltage Interval (V) 24...24
Voltage Nominal (V) 24
Voltage Forward (Vf) 3
Power LED (W) 12
Power Luminaire (W) 14,4
System Power (W) 15,8
Efficiency Luminaire (lm/W) 78
Efficiency System (lm/W) 71
Energy Efficiency Class 2019/2015 G
Operation and Connection
Driver Included No
Driver Model Constant Voltage
Operating Temperature -20…+45
Max. Tc (°C) 70
Dimmable Yes
Color and material
Material Copper
Color White
Environmental Assessment Byggvarubedömningen
Measurement and installation
Operating Environment Indoor / dry locations
IP Degree of Protection 20
Protection Class III
Installation Surface mounted
Mounting Installation Self Adhesive Tape
Approval Marks CE
Length (mm) 1000
Width (mm) 8
Height (mm) 2
Weight (kg) 0,03
Fibres and strips
Min. Bend Radius (mm) 60
Min. Length (m) 0,1
Max. Length (m) 5
Cutting Increments (mm) 100
