Moon Public Cross I IK10

Variants

GTIN Item Name Color Luminaire Lumen (lm)
Moon Public Cross I IK10 Anthracite 7392971134352 Moon Public Cross I IK10 Anthracite Antracit 1070
Moon Public Cross I IK10 Grey 7392971134345 Moon Public Cross I IK10 Grey Grey 1120
Moon Public Cross I IK10 White 7392971134338 Moon Public Cross I IK10 White White 1230

Moon Public Cross I IK10 Anthracite A

Description
GTIN 7392971134352
Item Name Moon Public Cross I IK10 Anthracite
Warranty 5 years
Lighting Data
Light Source LED
Light Source Included (type) LED exchangeable
LED Colour Warm White
Colour Temperature (K) 3000, 4000
Colour Rendering Index (Ra) >80
Colour Consistency (SDCM) 4
Luminous Intensity (cd) 330
Luminaire Lumen (lm) 1070
Beam Angle (°) 110
Light sharing Symmetric
Light Outlet Direct
Number of Lamps (pcs) 1
Number of LED (pcs) 60
Technical data
Life Time L90 50 000h Ta 25°C
Nominel Life Time (h) 50000
Life Time Driver 50 000h/10%
Voltage (type) AC
Voltage Interval (V) 220...240
Voltage Nominal (V) 230
Line Frequency (Hz) 50
Power LED (W) 13
Power Luminaire (W) 16
System Power (W) 16
Efficiency LED (lm/W) 127
Efficiency Luminaire (lm/W) 67
Efficiency System (lm/W) 67
Energy Efficiency Class A
Operation and Connection
Driver Included Yes
Driver Type Built-in
Connection (type) Quick Terminal
Connection (mm2) 3x0,75-2,5
Through Wiring Yes
Strain Relief Yes
Operating Temperature -35...+45
Max. Tc (°C) 85
Dimmable No
Fuse B10 (pcs) 43
Fuse B16 (pcs) 63
Fuse C10 (pcs) 50
Fuse C16 (pcs) 77
Color and material
Material Diecasted, Aluminium
Material Housing/Enclosure Polycarbonate
Mercury Free Yes
Color Antracit
Color Code (RAL) 7016
Measurement and installation
Operation Environment Indoor, Outdoor
IP Degree of Protection 65
Installation Surface mounted
Mounting Installation Screw Mounting
Approval Marks CE
Impact Strength IK10
Filament Test IEC 695-2-1(°C) 650
Protection Class I
Height (mm) 121
Diameter (mm) 275
Weight (kg) 1,7

Images and downloads

Accessories

No accessories for this product.
