LEDstrip 24V IP67

Basic version of our 24V LEDstrip, with120 LED/m there is lots of light and good efficiency. The smaller gap between diodes gives a homogeneous light with opal cover also in lower profiles. Comes in 5m lengths with self-adhesive tape, 2m connecting cable, 1m extra connecting cable, as well as 2 x 10cm shrink hoses, 10 clips and 20 screws. Also available made to measure in optional lengths with 50mm cut-off intervals and maximum length 10m.. Drivers are ordered separately according to required dimmer technology and placing.

Variants

GTIN Item Name Colour Temperature (K) Luminaire Lumen (lm)
LEDstrip 24V IP67 Midlum 2700K lpm 7392971141947 LEDstrip 24V IP67 Midlum 2700K lpm 2700 970
LEDstrip 24V IP67 Midlum 2700K 5m 7392971141930 LEDstrip 24V IP67 Midlum 2700K 5m 2700 4850
LEDstrip 24V IP67 Midlum 3000K 5m 7392971141954 LEDstrip 24V IP67 Midlum 3000K 5m 3000 4950
LEDstrip 24V IP67 Midlum 3000K lpm 7392971141961 LEDstrip 24V IP67 Midlum 3000K lpm 3000 990
LEDstrip 24V IP67 Midlum 4000K 5m 7392971141978 LEDstrip 24V IP67 Midlum 4000K 5m 4000 5200
LEDstrip 24V IP67 Midlum 4000K lpm 7392971141985 LEDstrip 24V IP67 Midlum 4000K lpm 4000 1040

LEDstrip 24V IP67 Midlum 2700K lpm

Description
GTIN 7392971141947
Item Name LEDstrip 24V IP67 Midlum 2700K lpm
Warranty 5 years
Light Technical Data
Light Source LED
Light Source Included Yes
LED Colour Warm White
Colour Temperature (K) 2700
Colour Rendering Index (Ra) >90
Colour Consistency (SDCM) 3
Initial Chromaticity (0.4569, 0.4094)
Luminous Intensity (cd) 310
Luminaire Lumen (lm) 970
Beam Angle (°) 120
Light sharing Symmetric
Light Outlet Direct
Number of Lamps (pcs) 1
Number of LED (pcs) 120
LED Pitch (mm) 8
Life Time L70 50 000h Ta 25°C
Nominel Life Time (h) 50000
Lumen maintenance 50 000h L77
Lumen maintenance 75 000h L71
LLMF @ 50 000h 0,77
Technical data
Voltage (type) DC
Voltage Interval (V) 24...24
Voltage Nominal (V) 24
Voltage Forward (Vf) 3
Power Luminaire (W) 12
System Power (W) 13,2
Efficiency Luminaire (lm/W) 81
Efficiency System (lm/W) 73
Energy Efficiency Class 2019/2015 F
Operation and Connection
Driver Included No
Driver Model Constant Voltage
Connection (mm2) 2x0,5
Operating Temperature -20…+45
Max. Tc (°C) 75
Dimmable Yes
Color and material
Material Copper
Color White
Environmental Assessment Byggvarubedömningen
Measurement and installation
Operating Environment Indoor / bathroom (ceiling area 1), Outdoor
IP Degree of Protection 67
Protection Class III
Installation Surface mounted
Mounting Installation Clips, Self Adhesive Tape
Approval Marks CE
Requires cooling No
Length (mm) 1000
Width (mm) 10
Height (mm) 6
Weight (kg) 0,08
Fibres and strips
Min. Bend Radius (mm) 30
Min. Length (m) 0,05
Max. Length (m) 10
Cutting Increments (mm) 50
